Rx280-4i16

Rx280-4i16
Gallery Image
Rx280-4i16
Key Applications
Ideal for

Hyper-Converged Infrastructure (HCI), Networking, host bus adapters (HBA), or RAID configurations

Key Features
Rx280-4i16

12 spacious 3.5” SAS/SATA bays, providing ample storage capacity for a variety of applica􀀁ons

Product SKUs
SuperServer Rx280-4i-16
Motherboard
Intel® Emmitsburg PCH C741 CPU Interconnection: 12.8, 14.4, and 16GT/s Socket Type: Socket E (LGA 4677)
Processor
Processor •5th Gen Intel® Xeon® Scalable Processors (Emerald Rapids) •4th Gen Intel® Xeon® Scalable Processors (Sapphire Rapids) •Supports CPU TDP up to 350W.
System Memory
Memory • DDR5 4800MHz (1DPC); DDR5 5600MHz (1DPC) by Emerald Rapids CPU • Total 16 memory slots; 8 slots per CPU (1DPC)
On-Board Devices
On-board Devices 6 SATA to front edge connectors (SATA 6Gb/s)
Input / Output
Rear I/O AN: 1 x GbE RJ45 dedicated/shared BMC management USB: 2 x USB 3.2 Gen1 Type A Video Output: 1 x DB15 connector
System BIOS
BIOS BIOS Type: AMI UEFI BIOS BIOS Features : •ACPI •PXE •WOL •AC loss recovery •BIOS recovery •IPMI 2.0 KCS mode interface •SRIOV •SMBIOS •TPM •Serial console redirection •PCIe hotplug
PC Health Monitoring
Environmental Specifications •Storage temperature : -10ºC(14ºF) ~ 60ºC(140ºF) •Operating temperature : 0ºC(32ºF) ~ 35ºC(95ºF) •Storage operating humidity : 5%~95% non-condensing
Expansion Slots
Expansion Slots • 2 x PCIe X16 slots (HHHL) • 1 x OCP 3.0 bay (PCIe X16 width)
System Cooling
System Cooling 4 x 80x80mm easy swap fans
Power Supply
Power Supply 3000W 1+1 CRPS 80+ Platinum
Others
Drive Bays External •12 x 3.5" hot-swap (3 x drives per node) Internal •2 x M.2(NGFF)/ M-Key/ 2280/ Support SATA or PCIe 4.0 X4
BMC Aspeed AST2600 Advanced PCIe Graphics & Remote Management Processor •Baseboard Management Controller •Intelligent Platform Interface 2.0 (IPMI 2.0) •iKVM, Media Redirection, IPMI over LAN, Serial over LAN •HTML5 •Redfish •SMASH Support
Network Controllers •Realtek RTL8211F GbE PHY for dedicated management port •Intel® i210 GbE NIC for shared management port
Graphics A speed AST2600 Advanced PCIe Graphics & Remote Management Processor •PCIe Graphic/2D Controller •1920x1200@60Hz 32bpp
Data Sheets

Rx280-4i16

View Download
Drivers

Drivers NoFound.

Certificates

Certificates NoFound.

product manual

product manual NoFound.

Optional Parts List
Part Number Qty Description
No optional parts available
