Chipset

Intel B760

CPU SUPPORT

Support for 12th / 13th /14th Generation Intel® Core™ i9/ i7/ i5/ i3 processors and Intel Pentium processors/

Intel Celeron processors in the LGA1700 package

MEMORY

Supports Dual Channel DDR5 - 6000+(OC) MT/s, Non-ECC, Un-buffered,

Clocked Unbuffered DIMM (CUDIMM) Memory

2 x DDR5 DIMM Memory Slot, Max. Supports up to 64 GB @ 6400Mhz

Support Intel® Extreme Memory Profile (XMP) memory modules

INTEGRATED VIDEO

Supports DX12

Supports HDCP

STORAGE

Total supports 2 x M.2 socket and 4 x SATA III (6Gb/s) ports

Intel 12th/13th/14th Processors

1 x M.2 2230 Wifi

PCIe CNVi Wifi

Intel B760 Chipset

2 x M.2 (M Key) Socket (M2M_SB):

Supports M.2 Type 2242/2260/2280 SSD module

Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD

4 x SATA III Connector (6Gb/s): Supports AHCI, RAID 0, 1, 5, 10 & Intel

Rapid Storage Technology

LAN

Realtek RTL8125B

10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability

AUDIO CODEC

REAR I/O

INTERNAL I/O

EXPANSION SLOT

ALC897

7.1 Channels, High Definition Audio, Hi-Fi (Front)

2 x HDMI

1 x DP

1 x VGA

1 x JBAT(Clear CMOS)

4 x USB 3.2 (Gen1) Port

2 x USB 2.0 port

1 x 2.5G LAN port

3 x Audio Jack

1 x M.2 (E Key) Socket: Supports 2230 type Wi-Fi & Bluetooth module and Intel CNVi

1 x USB 2.0 Header (each header supports 2 USB 2.0 ports)

1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)

1 x 8-Pin Power Connector

1 x 24-Pin Power Connector

1 x CPU Fan Connector

1 x CPU water cooling connector (CPU_OPT)

1 x System Fan Connector

1 x Front Panel Header

1 x Front Audio Header

1 x Internal Stereo Speaker Header

1 x Clear CMOS Header

1 x COM Port Header

2 x LED Header (5V)

1 x PCIe 4.0 x16 Slot (x16 mode)

INTEL B760 Chipset

1 x PCIe 3.0 x16 Slot (x4 mode)

Smart / Manual CPU Fan Control

CPU/DDR Voltage Monitoring

1 x I/O Shield

1 x DVD Driver

1 x Quick Guide

1 x M.2 Anchor

1 x WiFi antenna accessories
