Dx410P

Dx410P
Gallery Image
Gallery Image
Dx410P
Key Applications
Ideal for

Budget desktops and business systems, it delivers reliable performance with simplified features, the Intel B760 chipset provides you with the power and performance you need.

Key Features
Exatron Dx410P

Provide a stable, secure, and high-performance foundation for demanding business applications, leveraging the latest Intel processor technology and the speed of DDR5 memory. It supports Intel's 12th, 13th and 14th Gen processors, offering reliable performance for essential computing needs.

Product SKUs
SuperServer Dx410P
Motherboard
Intel® B760 Chipset
Processor
Processor Support for 12th/13th/14th Generation Intel Core™ i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Celeron processors in the LGA1700 package
System Memory
Memory •Supports Dual Channel DDR5 - 6000+(OC) MT/s, Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM) Memory, •2 x DDR5 DIMM Memory Slot, Max. Supports up to 128 GB Memory, • Support Intel® Extreme Memory Profile (XMP) memory modules
On-Board Devices
Onboard Graphics By CPU model Supports DX12 Supports HDCP
Chassis
Form Factor Micro ATX
Dimensions and Weight
Dimensions (W x L) 20.8cm x 23.6cm ( W x L )
Expansion Slots
Expansion Slots Intel 12th/13th/14th Processors, 1 x PCIe 4.0 x16 Slot, Intel B760 Chipset,1 x PCIe 3.0 x1 Slot
Drive Bays / Storage
Storage Interface •Total supports 1 x M.2 socket and 6 x SATA III (6Gb/s) ports Intel B760 Chipset, 1 x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA): • Supports M.2 Type 2242 /2260 /2280 SSD module, • Supports PCIe 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD & SATA SSD, • 4 x SATA III Connector (6Gb/s): Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology
Operating Environment
OS Supports Windows 10(64bit) / Windows 11(64bit)
Others
LAN Realtek RTL8125B, 10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability
Audio Realtek ALC897 High Definition Audio 7.1 Channels
USB 4 x USB 3.2 (Gen1) port (2 on rear I/Os and 2 via internal headers) 8 x USB 2.0 ports (2 on rear I/Os and 6 via internal headers)
Data Sheets

Dx410P

View Download
Drivers

Drivers NoFound.

Certificates

Certificates NoFound.

product manual

product manual NoFound.

Optional Parts List
Part Number Qty Description
No optional parts available
