Dx410S

Dx410S
Gallery Image
Gallery Image
Dx410S
Key Applications
Ideal for

Everyday computing, budget desktops and business systems

Key Features
Exatron Dx410S

Table, Secure, and High-performance foundation for demanding business applications, leveraging the latest Intel processor technology and the speed of DDR4 memory

Product SKUs
SuperServer Dx410S
Motherboard
Intel® B760
Processor
Processor Support for 12th/13th/14th Generation Intel Core™ i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Celeron processors in the LGA1700 package
System Memory
Memory Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2933/ 3200/ 3600(OC)/ 3800(OC)/ 4000(OC)/ 4400+(OC), 2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory, Each DIMM supports non-ECC 4/8/16/32GB DDR4 module, Support Intel® Extreme Memory Profile (XMP) memory modules
Input / Output
BIOS •AMI / 32MB •Hardware Monitor / Boot from USB device/PXE via LAN/Storage / Console Redirection / User Configurable FAN PWM Duty Cycle / SMBIOS 3.0/PnP/Wake on LAN / ACPI 6.1 / ACPI sleeping states S4,S5
Chassis
Chassis Form Factor Micro ATX
Dimensions and Weight
Dimensions (W x L) 23.6cm x 20.8cm (W x L)
Expansion Slots
Expansion Slots INTEL 12th/13th/14th Processors, 1 x PCIe 4.0 x16 Slot, INTEL H610 Chipset 1 x PCIe 3.0 x1 Slot, Intel B760 Chipset,1 x PCIe 3.0 x1 Slot
Drive Bays / Storage
Storage Interface Total supports 1 x M.2 socket and 4 x SATA III (6Gb/s) ports Intel B760 Chipset, 1 x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA):, Supports M.2 Type 2242/2260/2280 SSD module Supports PCIe 4.0 x4 (32Gb/s) - NVMe/AHCI SSD & SATA SSD, 4 x SATA III Connector (6Gb/s): Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology, 1 x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA), Supports M.2 Type 2242/2260/2280 SSD module Supports PCIe 4.0 x4 (32Gb/s) - NVMe/AHCI SSD & SATA SSD, 4 x SATA III Connector (6Gb/s): Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology
Operating Environment
OS Supports Windows 10(64bit) / Windows 11(64bit)
Others
Onboard Graphics - By CPU model Supports DX12 Supports HDCP
LAN Realtek RTL8125B 10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability
Audio Realtek ALC897 High-Definition Audio 7.1 Channels
USB 4 x USB 3.2 (Gen1) port (2 on rear I/Os and 2 via internal headers) 8 x USB 2.0 ports (4 on rear I/Os and 4 via internal headers)
Data Sheets

Dx410S

View Download
Drivers

Drivers NoFound.

Certificates

Certificates NoFound.

product manual

product manual NoFound.

Optional Parts List
Part Number Qty Description
No optional parts available
